Electrical Tools

Engineering Calculators

Preliminary sizing tools for practicing the same calculations covered in our technical courses.

Conductor Sizing

Four independent engineering sizing tools ā€” HT cables, LV cables, busducts and earthing conductors ā€” each performing real IEC/IS-aligned calculations rather than a rough estimate.

Design Inputs
Results
Demand Load
80.00 kW
Design Current
123.66 A
Final Recommended Cable Size
25 mmĀ²
Current Carrying Capacity
127.00 A
Utilization
97.4%
Voltage Drop
2.18%
Recommended Breaker
125 A
Protective Device Compatibility
Ib ā‰¤ In ā‰¤ Iz OK
Short Circuit Check
98.9 mmĀ² req.
FAIL
Cable utilization at 97% ā€” limited headroom.
Selected conductor cross-section is below the adiabatic short-circuit withstand requirement.
Calculation Formulas & Methodology
  1. Demand Load (kW) = Connected Load Ɨ Diversity Factor
  2. Design Current (A) = (Demand Load Ɨ 1000) Ć· (V Ɨ PF) for 1Ļ†, or Ć· (āˆš3 Ɨ V Ɨ PF) for 3Ļ†
  3. Current Carrying Capacity Iz (A) = Base Ampacity Ɨ Ambient Factor Ɨ Grouping Factor Ɨ Material Factor Ɨ Installation Factor Ɨ Formation Factor
  4. Final Recommended Cable Size = smallest standard size where Iz ā‰„ Design Current
  5. Voltage Drop (%) = [k Ɨ I Ɨ L Ɨ (RĀ·cosĻ† + XĀ·sinĻ†)] Ć· V Ɨ 100 (k = 2 for 1Ļ†, āˆš3 for 3Ļ†)
  6. Short-Circuit Minimum Cross-Section (mmĀ²) = (Fault Current Ɨ āˆšFault Duration) Ć· K (IEC 60364-5-54)
  7. Protective Device Compatibility: Ib (design current) ā‰¤ In (breaker rating) ā‰¤ Iz (cable capacity)
Indicative preliminary sizing tool aligned in principle with IEC 60364-5-52/5-54 and IS 732/IS 1255. Verify against manufacturer cable data sheets and the applicable local wiring regulation before final design.
Values shown are indicative, simplified reference figures for preliminary/learning purposes and are aligned in principle with the IEC 60364, IEC 60076, IEC 62040, ISO 8528, IEC 60909, IEEE 80, IEEE 141, EN 12464-1 and TIA-942 standards. Always verify against a manufacturer's datasheet and the applicable standard before using these figures on a real project.
Electrical Simulation

Interactive Physics Simulators

Beyond the calculators ā€” visual, interactive simulations for building intuition around the electrical fundamentals behind the numbers.

Generator Physics Simulator

A synchronous generator rotor spins inside a fixed stator. Change the pole count and grid frequency to see synchronous speed respond in real time (Ns = 120f / P), watch magnetic flux sweep past each phase winding, and read the resulting Faraday's-Law EMF and three-phase sine waves as they're generated.

Synchronous speed (Ns = 120f / P)Faraday's Law (E = āˆ’N dĪ¦/dt)Three-phase EMF generation
Launch Simulator

Electron Drift vs. Field Speed

Close the switch and a lamp meters away lights up almost instantly ā€” because the electric field propagates through the conductor at a large fraction of the speed of light. But the electrons that actually carry the current only drift at a snail's pace. Adjust the current and wire size and compare both speeds directly.

Electric field propagation speedElectron drift velocity (vd = I / nAq)Energy flow (Poynting vector)
Launch Simulator
Opens in a new tab. Best viewed on a laptop or desktop screen.
